Page 8 - SD 2205

APPLICATIONS  Oil and Gas industry including sour gas applications
 Pulp and Paper industry (digesters...)
 Chemical industry (reactor vessels...)
 Acetic acid distillation towers
 Phosphoric acid plants (reactors...)
 Sulphuric acid processes (hydrometallurgy...)
 Pollution control equipments
 Truck, lorries
 Chemical tankers

SIZE RANGE Hot rolled plates Cold rolled plates Clad plates
5 to 150 mm 2 to 14 mm 6 to 150 mm
Thickness 3/16" to 6" 5/64" to 5/8" 1/4" to 6"
Up to 3300 mm Up to 2300 mm Up to 3300 mm
Width Up to 130" Up to 90.5" Up to 130"
Up to 12000 mm Up to 8250 mm Up to 14000 mm
Length Up to 472" Up to 325" Up to 551"
Other sizes are available on request, including 4100mm (161,4") width plates

NOTE
This technical data and information represents our best knowledge at the time of printing. However, it may
be subject to some slight variations due to our ongoing research programme on corrosion resistant grades.
We therefore suggest that information be verified at time of enquiry or order.
Furthermore, in service, real conditions are specific for each application. The data presented here is only for
the purpose of description, and may only be considered as guarantees when our company has given written
formal approval.
Further information may be obtained from the following address.
